Home FS Audio Line ArraysDual 4 Inch Line Array System
2
| Specification | ||
| Model No. | Linx-204G2 | Linx-204G2SUBA |
| LF Driver | 2×4"（8Ohms, 1"VC) Woofer | 1×12"（4Ohms,3"VC,Neo) subwoofer |
| HF Diver | 1×1.35"driver(8 Ohms) | / |
| Input /Output Connection | Speakon | XLR/JACK COMBO |
| Frequency Response (Hz) | 100~18K(-3dB) | 40~1000(-3dB) |
| Impedance(Ohms) | 16 | 4 |
| RMS Power(W) | 100 | 500 |
| Program Power(W) | 200 | 1000 |
| Sensitivity(dB)(1w/1m) | 98 | 96 |
| Product Weight (kg) | 7.5 | 22 |
| Gross Weight (kg) | 8.5 | 26 |
| Cabinet Size(cm) | 45.3×22.1×14.6 | 35.5×46×44.5 |
| Shipping Carton Size (cm) | 55×32.5×69(4pcs) | 47.5×55.7×56 |
| Passive/Active | Passive | Active |
| Amplifier Module | ||
| Output Power (EIA test standard,100HZ 1%THD) | SAT: 500W/4 Ohms | |
| SUB: 500W/4 Ohms | ||
| S/N | 85 dB | |
| Damping Factor | > 500 @100 Hz | |
| Protection | over voltage protection up to 264V AC, overload output protection, clip, limiter | |
| Drawing |
|
|
